Trojan® Gravity Flow Oval Duct 85 Connector Kit #13285A Bulk

The Gravity Flow Nipple Connector and locknut fits into a 7/8” hole in the side of a plastic or metal barrel or even PVC pipe. Any of the Trojan Watering nipples can then be easily installed using pipe thread tape or pipe dope. You now have the industry’s finest Gravity Flow Nipple to water your animal.

• Sealing ring resists buckling or slipping during installation
• Sealing ring is designed to provide a complete 360° seal, even when it is not perpendicular with your barrel
• Locknut enables easy application of torque with wrench
• Sharper and deeper teeth to improve bonding
• Precision machined tapered threads designed to create a watertight union

---

INSTALLATION INSTRUCTIONS

Equipment needed:

• Container being used to hold water
• 7/8" drill bit to drill hole
• Thread sealing tape or pipe dope

Instructions:

1. Drill 7/8" hole in desired placement of the container
2. Separate and install the Connector into the hole
3. Apply thread sealing tape or pipe dope to nipple threads for water tight seal
4. Install the nipple into the connector kit.

---

TIPS:

DO NOT allow nipple to freeze

DO NOT tighten with pipe wrench
